Live Stream Encoder Configuration and Required Dacast Settings
Introduction To Live Encoding
To ensure your Dacast live stream is stable and fully functional, you MUST configure your encoder to use the settings defined on this page. These settings have been chosen to ensure the maximum compatibility with the Dacast platform as well as with newer and older devices that are used for live streaming on your website ( Desktop, Mobile, SmartTVs, etc.) In this article you will find:
- Common Settings that must be used for all live streaming on the Dacast platform
- Resolution & Bitrate Settings that differ based on the desired size and quality of your stream
- Unsupported Settings that must not be used or you will see problems with your stream
- Encoder Download Links to get your hands on a software encoder
1. Required Live Encoder Settings
The following settings are required for live streaming with Dacast, regardless of your selected resolution and bitrate:
| Video Codec | H.264 (x264 may work) |
|---|---|
| Frame Rate | 25 or 30 |
| Keyframe Interval | 2 seconds (every 60 or 120 frames depending on frame rate) |
| Scanning | Progressive |
| Rate Control | Constant (CBR) |
| Audio Codec | AAC-LC |
| Audio Bitrate | 128 kbps |
| Audio Channels | 2 (Stereo) |
| Audio Sample Rate | 48 kHz (48,000 Hz) |
Please, avoid these values:
Video codec: H.265
Scanning: Interlaced
Rate control: ABR, VBR
2. Resolution & Bitrate Settings
Please select one of the following video configurations and ensure your encoder is set up with these exact settings to help prevent streaming issues:
| Name | Resolution (px) | Frame Rate | Video Bitrate (kbps) | H.264 Profile |
|---|---|---|---|---|
| 240p (Ultra-Low) | 426×240 | 30 fps | 300 – 500 | Main |
| 360p (Low) | 640×360 | 30 fps | 600 – 1000 | Main |
| 480p (SD) | 854×480 | 30 fps | 1000 – 2000 | Main |
| 720p (HD) | 1280×720 | 30 fps | 2500 – 4000 | High |
| 720p (HD) | 1280×720 | 60 fps | 3500 – 6000 | High |
| 1080p (FHD) | 1920×1080 | 30 fps | 4500 – 6000 | High |
| 1080p (FHD) | 1920×1080 | 60 fps | 6000 – 9000 | High |
| 1440p (2K) | 2560×1440 | 30 fps | 8000 – 15000 | High |
| 1440p (2K) | 2560×1440 | 60 fps | 12000 – 24000 | High |
| 2160p (4K UHD) | 3840×2160 | 30 fps | 16000 – 34000 | High |
| 2160p (4K UHD) | 3840×2160 | 60 fps | 20000 – 51000 | High |
Before going live, we invite you to do a speed test first (testmy.net/) at the place where you will be live streaming. If you have any questions about your encoder settings, you can reach out to our support team and send screenshots of your encoder settings.
3. Encoder Download and Stream Guide Links
- Dacast OBS Studio
- Telestream Wirecast
- vMix
- VID BlasterX
- SlingStudio
- Download
- Stream Guide
- Teradek
- LiveU
- Switchboard live:
Any questions or need help/access to this feature? Please contact us. Not yet a Dacast user, and interested in trying Dacast risk-free for 14 days? Sign up today to get started.
Additional Resources
1. More on Video Transcoding
Encoding is a process used to convert the RAW video files captured by a camera into digital files suitable for live streaming over the internet. This process uses either a hardware or software encoder.
